| System Compression | H.265S/H.265+/H.265/H.264 |
|---|
| Operating System | Embedded Linux |
|---|
| IP Camera Input | 64CH |
|---|
| Video Output | HDMI1 x 1: 8K
HDMI2 & HDMI3: 4K HDMI4: 1920 × 1080
VGA x 1: 1920 × 1080
HDMI1 & VGA output the same video |
|---|
| Audio In | 1CH RCA, 64CH IPC |
|---|
| Audio Out | 1CH |
|---|
| 2 Way Audio | Yes |
|---|
| Decoding Capability | 1CH @ 16MP / 4CH @ 12MP |
|---|
| Recording Resolution | 16MP/12MP/8MP/6MP/5MP/4MP/3MP/1080P/1280x1024/960P/720P/960H/D1/CIF |
|---|
Playback Channels | 16CH |
|---|
Playback Search
| Time/Calendar Search, Event (motion), Tag, Smart Search |
|---|
|
|
|---|
Playback Function
| Play, pause, FF, Rewind, digital zoom, previous frame, next frame, etc. |
|---|
Alarm Mode
| Manual, sensor, motion, exception, smart events |
|---|
Alarm In
| 16ch
|
|---|
| Alarm Out | 4ch |
|---|
Trigger Events
| Record, snap, preset, e-mail, etc. |
|---|
| Face Detection (by IPC) | 64ch |
|---|
| Face Detection (by NVR) | 4ch |
|---|
| Face Match Performance | 16ch |
|---|
| Comparison Capability | 36 pictures/second |
|---|
| Face Picture Database | 32 libraries
10,000 face pictures |
|---|
| Search by Picture | Supported |
|---|
| Database Management | Add, modify, delete, and search pictures |
|---|
| Face Picture Adding | Add face pictures through App, Web, or external import |
|---|
| Face Picture Comparison | Supports allowlist, blocklist, and strange match alarm |
|---|
| Face Statistics | Statistics by day, week, month, quarter, and custom time period |
|---|
| Human/Vehicle Classification | Supported 64ch by IPC 8ch by NVR |
|---|
| PoE | N/A |
|---|
| PoE Standard | N/A |
|---|
| PoE Output Power | N/A |
|---|
| Network Interface | RJ45 1000Mbps × 2 |
|---|
| Incoming Bandwidth | 640Mbps |
|---|
| Outgoing Bandwidth | 640Mbps |
|---|
| Network Protocol | TCP/IP, HTTP, HTTPS, 802.1x, FTP, DHCP, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IPv6, UDP, WebSocket, PPPoE, SNMP, IGMP |
|---|
| Network Max. Users | 128 users online |
|---|
| Mobile | iPhone, Android |
|---|
| Internal HDD | 8x SATA, max 10T per HDD, 2x eSATA for external HDD |
|---|
RS485 | Yes (full-duplex), connect to PTZ or keyboard |
|---|
| USB | USB 2.0 x 2 , USB 3.0 x 1 |
|---|
| Power Supply | ATX 200W |
|---|
| Power Consumption | ≤ 50W (without HDD) |
|---|
| Operating Conditions | -10 ～ 50 ℃，10% ～ 90% humidity |
|---|
| Dimensions | 445 x 436 x 90mm (W x D x H) |
|---|
