Smart Features
|
8-ch Motion Detection 2.0
8-ch Perimeter Protection
4-ch Facial Recognition
8-ch Direct Search Technology
*Not all smart features can be enabled at the same time
|
| Analog Video Input |
8-ch BNC
|
| IP Video Input |
8-ch (up to 16-ch), up to 8MP |
| HDMI Output |
1-ch, 4K (3840 × 2160)/30Hz,
2K (2560 × 1440)/60Hz,
1920 × 1080/60Hz,
1280 × 1024/60Hz,
1280 × 720/60Hz
HDMI/VGA simultaneous output |
| VGA Output |
1-ch, 1920 × 1080/60Hz,
1280 × 1024/60Hz,
1280 × 720/60Hz |
| HDTVI Input |
8 MP(3840 × 2160)@12/15 fps, 3K(2960 x 1665)@25/20 fps,3K(3328x1504)@20fps,5
MP(2560 × 1944)@20 fps, 4 MP(2560 × 1440)@25/30 fps,1080P@25/30 fps,
720P@25/30fps |
| AHD Input |
5 MP(2560 × 1944)@20 fps, 4 MP(2560 × 1440)@25/30 fps,1080P@25/30 fps,
720P@25/30fps |
| HDCVI Input |
8 MP(3840 × 2160)@12/15 fps, 3K(2880×1620)@25/20fps, 5 MP(2592 × 1944)@20
fps, 4 MP(2560 × 1440)@25/30 fps,1080P@25/30 fps, 720P@25/30fps |
| Audio IO |
1-ch RCA Output, 1-ch RCA Input, 8-ch input via coaxial cable |
| Alarm IO |
NA |
| SATA Interface |
1 SATA input, up to 12TB HDD |
| Serial Interface |
RS-485 (half-duplex) |
| USB Interface |
1x USB 2.0, 2x USB 3.0 |
| Power Supply |
12VDC, 2A, ≤ 24W |
| Total Bandwdith |
256Mbps
|
| Network Protocol |
TCP/IP, PPPoE, DHCP, LTS Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS,
ONVIF, ISUP |
| Network Interface |
1, RJ45 10M/100M/1000M self-adaptive Ethernet interface |
| Video Compression |
H.265 Pro+/H.265 Pro/H.265/H.264+/H.264 |
| Encoding Resolution |
8MP/5MP/3K/4MP/3MP/1080p/720p/WD1/4CIF/VGA/CIF
|
|
|
| Dimensions |
320 × 240 × 48 mm (12.6 × 9.4 × 1.9 inch) |
| Weight |
≤ 2 kg (4.4 lb) |
