| Image Sensor | 1/2.5" CMOS |
|---|
| Max. Resolution | 2160x2160 |
|---|
| Electronic Shutter | 1/3s ~ 1/100,000s |
|---|
| Iris Type | Fixed |
|---|
| Min. Illumination | 0.01 lux @ F2.0, AGC ON, 0 lux with illumination on |
|---|
| Lens | 1.65mm@F2.0, horizontal FOV: 180 (wall mounting), 360 (ceiling mounting), 360 (desktop) |
|---|
Wide Dynamic Range | 120dB |
|---|
| S/N Ratio | ≥50dB |
|---|
| BLC & HLC | Supported |
|---|
| Video Compression | H.265+ / H.265 / H.264+ / H.264 / MJPEG |
|---|
| Streams | Mode1: Fisheye
Fisheye view (main stream): 2160×2160/1440×1440/1080×1080 (60Hz: 1~30fps)
Fisheye view (sub stream): 960×960/720×720/480×480 (60Hz: 1~30fps)
Fisheye view (third stream): 640×640/360×360(60Hz: 1~30fps)
Mode2: Panoramic
Panoramic view (main stream): 3200×1800/2560×1440/1920×1080 (60Hz:1~30fps)
Panoramic view (sub stream): 1280×720/640×360 (60Hz:1~30fps)
Panoramic view (third stream): 1280×720/640×360 (60Hz:1~30fps)
Mode 3: Fisheye+Panoramic+3 PTZ
Fisheye view (main stream): 2160×2160/1440×1440/1080×1080 (60Hz: 1~20fps)
Fisheye view (sub stream): 960×960/720×720/480×480 (60Hz: 1~20fps)
Fisheye view (third stream): 640×640/360×360(60Hz: 1~20fps)
Panoramic view (main stream): 3200×1800/2560×1440/1920×1080 (60Hz:1~20fps)
Panoramic view (sub stream): 1280×720/640×360 (60Hz:1~20fps)
Panoramic view (third stream): 1280×720/640×360 (60Hz:1~20fps)
3PTZ view: (1280×720) * 3 (60Hz: 1~20fps)
Mode 4: Fisheye+ 4 PTZ
Fisheye view (main stream): 2160×2160/1440×1440/1080×1080 (60Hz: 1~30fps)
Fisheye view (sub stream): 960×960/720×720/480×480 (60Hz: 1~30fps)
Fisheye view (third stream): 640×640/360×360(60Hz: 1~30fps)
4PTZ view : (1280×720) * 4 (60Hz: 1~15fps)
Mode5: Fisheye+ 4 PTZ Fusion
Fisheye view (main stream): 2160×2160/1440×1440/1080×1080 (60Hz: 1~30fps)
Fisheye view (sub stream): 960×960/720×720/480×480 (60Hz: 1~30fps)
Fisheye view (third stream): 640×640/360×360(60Hz: 1~30fps)
4PTZ fusion view (main stream): 2560×1440 (60Hz: 1~20fps)
4PTZ fusion view (sub stream): 640×360 (60Hz: 1~20fps)
4PTZ fusion view (third stream): 640×360 (60Hz: 1~20fps) |
|---|
| Bit Rate | 64Kbps ~10Mbps |
|---|
| Bit Rate Type | VBR / CBR |
|---|
| Image Settings | ROI, Saturation, Brightness, Hue, Contrast, Wide Dynamic, Sharpness, Image Flip, Image Mirror, NR, etc. |
|---|
| ROI | Supported |
|---|
| Network Port | RJ45 |
|---|
| Video Output | CVBS (BNC x 1) |
|---|
| Audio | 2ch built-in microphone, 1ch audio input, 1ch audio output |
|---|
| Alarm | 1ch alarm input, 1ch alarm output |
|---|
| RS-485 | Yes, half-duplex |
|---|
| Storage | Built-in microSD card slot, max. 256GB (not included) |
|---|
| Network Protocol | UDP, IPv4, IPv6, DHCP, NTP, RTSP, RTP, RTCP, RTMP, SNMP, PPPoE, DDNS, 802.1x, SMTP, FTP, UPnP, HTTPS, HTTP, QoS, P2P, HTTP POST |
|---|
| Interface Protocol | ONVIF |
|---|
| Smart Alarm | Motion detection, sensor alarm, SD card error, SD card full, IP address conflict, cable disconnection |
|---|
| Intelligent Analytics | Mode 1/3/4/5 (ceiling mounting): (Human) region intrusion/region entrance/region exiting/line crossing/target
counting by line, crowd density detection, heat map
Mode 2/3 (Wall mounting or desktop): Region intrusion/region entrance/region exiting/line crossing/target counting
by line (human/motor vehicle/non-motor vehicle classification), crowd density detection |
|---|
| General Function | Watermark, video mask, heartbeat, corridor pattern, fisheye dewarping, system backup |
|---|
| PoE | IEEE 802.3af |
|---|
| Supplement Light Range | IR max. range 10~20m (32~66 feet) |
|---|
| Ingress Protection | IP67 |
|---|
| Power Supply | PoE or 12VDC |
|---|
| Power Consumption | <10W |
|---|
| Operating Conditions | -30 °C ~ 60 °C (-22°F~140°F), Humidity: less than 95 % (non-condensing) |
|---|
| Dimensions (mm) | Φ 130.6 x 46.3 |
|---|
| Weight | ~0.52kg |
|---|
| Mounting Options | Ceiling, wall, or desktop |
|---|
