| System Compression | H.265S/H.265+/H.265/H.264 |
|---|
| Operating System | Embedded Linux |
|---|
| IP Camera Input | 128CH |
|---|
| Video Output | HDMI1 x 1: 8K
HDMI2 & HDMI3: 4K
HDMI4: 1920 × 1080
VGA x 1: 1920 × 1080
HDMI1 & VGA output the same video When the resolution of HDMI1output is 8K, HDMI2 is unavailable and the maximum resolution of HDMI3 output is 1920×1080 |
|---|
| Audio In | 1CH RCA, 128CH IPC |
|---|
| Audio Out | 1CH |
|---|
| 2 Way Audio | Yes |
|---|
| Decoding Capability | 1CH @ 16MP / 4CH @ 12MP |
|---|
| Recording Resolution | 16MP/12MP/8MP/6MP/5MP/4MP/3MP/1080P/1280x1024/960P/720P/960H/D1/CIF |
|---|
Playback Channels | 16CH |
|---|
Playback Search
| Time slice/time/event/tag/smart search |
|---|
| Playback Function | Play, pause, FF, Rewind, digital zoom, previous frame, next frame, etc. |
|---|
| Alarm Mode | Manual, sensor, motion, exception, smart events |
|---|
| Alarm In | 24ch |
|---|
| Alarm Out | 8ch |
|---|
| Trigger Events | Record, snap, preset, e-mail, etc. |
|---|
| Face Detection (by IPC) | 128ch |
|---|
| Face Detection (by NVR) | 4ch (4MP) |
|---|
| Face Match Performance | 16ch |
|---|
| Comparison Capability | 36 pictures/second |
|---|
| Face Picture Database | 32 libraries 10,000 face pictures |
|---|
| Search by Picture | Supported |
|---|
| Database Management | Add, modify, delete, and search pictures |
|---|
| Face Picture Adding | Add face pictures through App, Web, or external import |
|---|
| Face Picture Comparison | Supports allowlist, blocklist, and strange match alarm |
|---|
| Face Statistics | Statistics by day, week, month, quarter, and custom time period |
|---|
| Human/Vehicle Classification | Supported
128ch by IPC
8ch by NVR (2MP) |
|---|
| Other Functions | Supports fisheye de-warping via NVR/Web Client/mobile APP Plate Recognition by IPC |
|---|
| PoE | N/A |
|---|
| PoE Standard | N/A |
|---|
| PoE Output Power | N/A |
|---|
| Network Interface | RJ45 1000Mbps × 2 |
|---|
| Incoming Bandwidth | 768Mbps |
|---|
| Outgoing Bandwidth | 768Mbps |
|---|
| Network Protocol | TCP/IP, HTTP, HTTPS, 802.1x, FTP, DHCP, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IPv6, UDP, WebSocket, PPPoE, SNMP, IGMP |
|---|
| Network Max. Users | 128 users online |
|---|
| Mobile | iPhone, Android |
|---|
| Internal HDD | 16x SATA, max 10T per HDD (supports RAID 0,1,5,6,10), 2x eSATA for external HDD |
|---|
RS485 | Yes (full-duplex), connect to PTZ or keyboard |
|---|
| USB | USB 2.0 x 3, USB 3.0 x 1 |
|---|
| Power Supply | ATX 275W |
|---|
| Power Consumption | ≤ 50W (without HDD) |
|---|
| Operating Conditions | -10 ～ 50 ℃，10% ～ 90% humidity |
|---|
| Dimensions | 437 x 483 x 143mm (W x D x H) |
|---|
