| License Plate Recognition | Vehicle Plate Database: 10,000 (only when the SD card is available)
Detection & Recognition:
Capture of vehicles with license plates and vehicles without license plate,
Support plate exposure, travel direction recognition, plate character fault tolerance, plate comparison, snapshot time display
Vehicle feature extraction: including vehicle color, plate color, vehicle type, vehicle brand/model, etc.
Capture Speed Range: 0~50mph (0~80km/h) |
|---|
| Image Sensor | 1/1.8" CMOS |
|---|
| Max. Resolution | 2688x1520 |
|---|
| Electronic Shutter | 1/1s ~ 1/100,000s |
|---|
| Iris Type | DC Iris |
|---|
| Min. Illumination | 0.001 lux @ F1.6, AGC ON, 0 lux with illumination on |
|---|
| Lens | 2.8~12mm@F1.6, horizontal FOV: 109.5°~48.5° ; vertical FOV: 54°~26.5° ; diagonal FOV: 119°~55.8° |
|---|
| Recommended LPR Distance | 3~8m (10~26 feet) |
|---|
| Wide Dynamic Range | 120dB |
|---|
| BLC & HLC | Supported |
|---|
| S/N Ratio | ≥50dB |
|---|
| Angle Adjustment | Manual adjustment
Pan: 0°~360°; Tilt: 0°~90°; Rotation: 0°~360° |
|---|
| Video Compression | Main Stream: H.265+ / H.265 / H.264+ / H.264
Sub Stream / Third Stream: H.265+ / H.265 / H.264+ / H.264 / MJPEG |
|---|
| Resolution | 4MP ( 2688 × 1520), 2K ( 2560 × 1440 ), 3MP ( 2304 × 1296 ), 1080P ( 1920 × 1080 ), 720P ( 1280 × 720 ), D1, VGA (640× 480), CIF |
|---|
| Main Stream | 4MP/2K/3MP/1080P (1~30fps)
HFR Mode: 1080P (1~60fps) |
|---|
| Sub Stream | 720P/D1/CIF (1~30fps) |
|---|
| Additional Streams | Third Stream: D1/CIF (1~30fps) |
|---|
| Bit Rate | 64Kbps ~8Mbps |
|---|
| Bit Rate Type | VBR / CBR |
|---|
| Image Settings | ROI, Saturation, Brightness, Hue, Contrast, Wide Dynamic, Sharpness, Vertically flip, NR, etc. |
|---|
| ROI | Supported |
|---|
| Network Port | RJ45 |
|---|
| Video Output | CVBS output (BNC x1) |
|---|
| Audio | 1ch audio input, 1ch audio output |
|---|
| Alarm | 1ch alarm input, 1ch alarm output |
|---|
| RS 485 | Supported |
|---|
| Storage | Built-in microSD card slot, max. 256GB (not included) |
|---|
| Network Protocol | UDP, IPv4, IPv6, DHCP, NTP, RTSP, RTP, RTMP, RTCP, PPPoE, DDNS, SMTP, FTP, SNMP, HTTP, HTTP POST,802.1x, UPnP, HTTP , P2P, QoS |
|---|
| Interface Protocol | ONVIF |
|---|
Smart Alarm | Motion detection, sensor alarm, SD card error, SD card full, IP address conflict, cable disconnection, audio alarm |
|---|
| General Function | Watermark, IP address filtering, video mask, heartbeat, ANR, smart supplement light, corridor pattern |
|---|
| PoE | IEEE 802.3af |
|---|
| Supplement Light Range | IR max. range 50~70m (164~230 feet) |
|---|
| Ingress Protection | IP67 |
|---|
| Security | Video encryption, firmware encryption, HTTPS encryption, configuration encryption, illegal login lock, IP address filtering, 802.1x authentication, basic and digest authentication for HTTP/RTSP |
|---|
| Power Supply | PoE or 12VDC |
|---|
| Power Consumption | <12W |
|---|
| Storage Conditions | -30 °C ~ 65°C (-22°F~149°F), Humidity: less than 95 % (non-condensing) |
|---|
| Operating Conditions | -30 °C ~ 60 °C (-22°F~140°F), Humidity: less than 95 % (non-condensing) |
|---|
| Dimensions (mm) | 278.3 x 100.2 x 88.7 |
|---|
| Weight | ~1.176kg |
|---|
| Mounting Options | Ceiling & wall |
|---|
