| Image Sensor | 1/2.8" CMOS |
|---|
| Max. Resolution | 2560x1440 |
|---|
| Electronic Shutter | 1/1s ~ 1/100000s |
|---|
| Iris Type | Auto DC-IRIS, 16 Stops |
|---|
| Min. Illumination | Color: 0.01 lux @ F1.65, AGC ON
B/W: 0.002 lux @ F1.65, AGC ON
0 lux with IR illumination on |
|---|
| Lens | 4.8~120mm lens, 25x optical zoom
Horizontal FOV: 55°~2.4; vertical FOV: 33°~1.4 ° ; diagonal FOV: 61.5°~2.8 ° |
|---|
| Zoom Speed | ~3.6s (optical zoom, wide-tele) |
|---|
| Aperture Range | F1.65~F3.8 (wide-tele) |
|---|
| Pan/Tilt Settings | Pan: 360° endless, 0.1~200°/s configurable pan speed; preset speed: 240°/s
Tilt: -5 ° to 90 ° with auto flip; 0.1~200 °/s configurable tilt speed; preset speed: 240 °/s |
|---|
| Cruise | 8 cruises, up to 16 presets for each cruise |
|---|
| Trace | 4 traces, record time over 3 minutes for each trace |
|---|
| Video Compression | H.265 / H.264+ / H.264 / MJPEG |
|---|
| Main Stream | 2560×1440,1920×1080,1280×960,1280×720 @ 30fps |
|---|
| Sub Stream | 704 × 480, 640 × 480, 352 × 240 @ 30fps |
|---|
| Additional Streams | Third Stream: 1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240 @ 30fps |
|---|
| Bit Rate | 64Kbps ~8Mbps |
|---|
| Bit Rate Type | VBR / CBR |
|---|
| Network Port | RJ45 |
|---|
| Audio | 1ch audio input, 1ch audio output |
|---|
| Alarm | 1ch alarm input (dry contact), 1ch alarm output |
|---|
| Storage | Built-in microSD card slot, max. 256GB (not included) |
|---|
| Network Protocol | HTTP, HTTPS, IPv4/IPv6, 802.1x, QoS, FTP, SMTP, UPnP, SNMP,DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, DHCP, PPPoE |
|---|
| Interface Protocol | ONVIF |
|---|
| Basic Event | Motion detection, Video tampering alarm, Exception(Network disconnected, IP address conflict, SD full, SD error) |
|---|
| Face Recognize | Detecting max 15 faces at same scene. Detecting, tracking, capturing |
|---|
| Road Traffic | Vehicle detecting and tracking |
|---|
| Smart Detection | Tripwire, Bi-directional tripwire, Illegal intrusion detection, Region entrance detection, Region exitance detection, Unattended baggage detection, Object removal detection, etc. |
|---|
| Smart Tracking | Smart trackign of human or vehicle, auto/manual |
|---|
| PoE | IEEE 802.3at |
|---|
| Supplement Light Range | IR max. range 150m (~492 feet) |
|---|
| Ingress Protection | IP66 |
|---|
| Security | User authentication (ID and PW), Host authentication (MAC address); HTTPS encryption, IEEE802.1x port-based network access control; IP address filtering |
|---|
| Power Supply | PoE+ or 12VDC |
|---|
| Power Consumption | <Max. 23W |
|---|
| Storage Conditions | -40°C ~ 70°C ; ≤ 95% RH |
|---|
| Operating Conditions | -40 °C ~ 60°C (-40°F~140°F), cold start @ -30°C (30 minutes waiting; Humidity: 90% RH |
|---|
| Dimensions (mm) | Φ173x247 (Φ6.8x9.7 inch) |
|---|
| Weight | ~2.1kg (~4.63 lb.) |
|---|
