| System Compression | H.265S/H.265+/H.265/H.264 |
|---|
| Operating System | Embedded Linux |
|---|
| IP Camera Input | 16CH |
|---|
| Video Output | HDMI x 1: 4K
VGA x 1: 1920 × 1080
Simultaneous or Independent |
|---|
| Audio In | 1CH |
|---|
| Audio Out | 1CH |
|---|
| 2 Way Audio | Yes |
|---|
| Decoding Capability | 1CH @ 12MP / 4CH @ 1080P |
|---|
| Recording Resolution | 12MP / 8MP (4K) / 6MP / 5MP / 4MP / 3MP / 2MP (1080P) / 1280x1024 / 960P / 720P / 960H / D1/ CIF |
|---|
Playback Channels | 16CH |
|---|
Playback Search
| Time/Calendar Search, Event (motion), Tag, Smart Search |
|---|
Playback Smart Search
| Highlighted color to display the camera record in a certain period of time, different colors refers to different record events |
|---|
Playback Function
| Play, Pause, FF, FB; Digital zoom |
|---|
Alarm Mode
| Manual, sensor, motion, exception, smart events |
|---|
Alarm In
| 8ch
|
|---|
| Alarm Out | 4ch |
|---|
Trigger Events
| Record, snap, preset, e-mail, etc. |
|---|
| Face Detection (by IPC) | 16ch |
|---|
| Face Detection (by NVR) | 2ch |
|---|
| Face Match Performance | 6ch |
|---|
| Comparison Capability | 18 pictures/second |
|---|
| Face Picture Database | 32 libraries
10,000 face pictures |
|---|
| Search by Picture | Supported |
|---|
| Database Management | Add, modify, delete, and search pictures |
|---|
| Face Picture Adding | Add face pictures through App, Web, or external import |
|---|
| Face Picture Comparison | Supports allowlist, blocklist, and strange match alarm |
|---|
| Face Statistics | Statistics by day, week, month, quarter, and custom time period |
|---|
| Human/Vehicle Classification | Supported |
|---|
| PoE | RJ45 100Mbps x 16 |
|---|
| PoE Standard | IEEE 802.3af/at |
|---|
| PoE Output Power | ≤ 150W |
|---|
| Network Interface | RJ45 1000Mbps × 1 |
|---|
| Incoming Bandwidth | 160Mbps |
|---|
| Outgoing Bandwidth | 160Mbps |
|---|
| Network Protocol | TCP / IP, PPPoE, DHCP, DNS, DDNS, UPnP, NTP, SMTP, HTTP, HTTPS, 802.1x, RTSP, SNMP, ONVIF, etc |
|---|
| Network Max. Users | 64 users online |
|---|
| Mobile | iPhone, Android |
|---|
| Internal HDD | 2x SATA, max 10T per HDD |
|---|
RS485 | Yes (full-duplex), connect to PTZ or keyboard |
|---|
| USB | USB 2.0 x 2 , USB 3.0 x 1 |
|---|
| Power Supply | DC 48V /3.75A |
|---|
| Power Consumption | ≤ 20W ( without HDD and PoE power supply) |
|---|
| Operating Conditions | -10 ～ 50 ℃，10% ～ 90% humidity |
|---|
| Dimensions | 380 x 268 x 45mm (W x D x H) |
|---|
