| Image Sensor | 1/3" CMOS |
|---|
| Max. Resolution | 5MP @ 20fps |
|---|
| Electronic Shutter | Auto |
|---|
| Min. Illumination | Color : 0.03 lux@F2.0, AGC ON; B/W: 0 lux with IR LEDs |
|---|
| Lens | 2.8mm |
|---|
| Focus | Fixed |
|---|
| Wide Dynamic Range | DWDR |
|---|
| Resolution | AHD/TVI: 5M@20fps/12.5fps, 4M@30fps/25fps/15fps, 2M@30fps/25fps;
CVI: 4M@30fps/25fps, 2M@30fps/25fps;
CVBS |
|---|
| Audio | NA |
|---|
| Supplement Light Range | IR max. range 25m (~82 feet) |
|---|
| Ingress Protection | IP67 |
|---|
| Power Supply | 12VDC, 500mA |
|---|
| Connector | BNC |
|---|
| Storage Conditions | -20 °C ~ 60°C (-4°F~140°F), Humidity: less than 95 % (non-condensing) |
|---|
| Operating Conditions | -10 °C ~ 60 °C (-14°F~140°F), Humidity: less than 95 % (non-condensing) |
|---|
| Dimensions (mm) | Φ96 x 91 |
|---|
| Weight | ~0.6kg |
|---|
