| Image Sensor | 1/3" CMOS |
|---|
| Max. Resolution | 2688x1520 |
|---|
| Electronic Shutter | 1/3s ~ 1/100,000s |
|---|
| Iris Type | Fixed |
|---|
| Min. Illumination | 0.005 lux @ (F1.6, AGC on), 0 lux with IR on |
|---|
| Lens | 2.8mm@F1.6, horizontal FOV: 103°; vertical FOV: 55°; diagonal FOV: 122° |
|---|
| Focus | Fixed |
|---|
| Wide Dynamic Range | 120dB |
|---|
| BLC & HLC | Supported |
|---|
| Angle Adjustment | Manual adjustment
Pan: 0°~360°; Tilt: 0°~90°; Rotation: 0°~360° |
|---|
| Video Compression | Main Stream: H.265+ / H.265 / H.264+ / H.264
Sub Stream: H.265+ / H.265 / H.264+ / H.264 / MJPEG |
|---|
| Resolution | 4MP ( 2688x1520), 1080P ( 1920x1080 ), 720P ( 1280x720 ) |
|---|
| Main Stream | 30fps @ 4MP (2688x1520) / 1080P (1920x1080) / 720P (1280x720) |
|---|
| Sub Stream | 30fps @ 640x480, 640x360 |
|---|
| Additional Streams | Third Stream: 30fps @ 1280x720, 640x480, 640x360
|
|---|
| Bit Rate | 32Kbps ~8Mbps |
|---|
| Bit Rate Type | VBR / CBR |
|---|
| Image Settings | Rotate, mirror, privacy mask, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser |
|---|
| ROI | Supported |
|---|
| Network Port | RJ45 |
|---|
| Audio | 1ch built-in microphone |
|---|
| Storage | Built-in microSD card slot, max. 256GB (not included) |
|---|
| Network Protocol | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS, PPPoE |
|---|
| Interface Protocol | ONVIF (Profile S, Profile G) |
|---|
| Smart Alarm | Motion detection (human and vehicle targets classification), video tampering alarm, exceptions / anomalies |
|---|
| Smart Event | Face detection, line crossing detection, and intrusion detection. Supports human and vehicle target classification |
|---|
| General Function | Anti-flicker, heartbeat, password reset via e-mail, pixel counter |
|---|
| PoE | IEEE 802.3af |
|---|
| Supplement Light Range | IR max. range 40m (131 feet) |
|---|
| Ingress Protection | IP67 |
|---|
| Security | Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for Open Network Video Interface |
|---|
| Power Supply | PoE or 12VDC |
|---|
| Power Consumption | <7W |
|---|
| Storage Conditions | -30°C ~ 60°C (-22°F~140°F), Humidity: less than 95 % (non-condensing) |
|---|
| Operating Conditions | -30°C ~ 60°C (-22°F~140°F), Humidity: less than 95 % (non-condensing) |
|---|
| Dimensions (mm) | Φ70x161.7 (Φ 2.76 × 6.37 in.) |
|---|
| Weight | ~0.49kg (~1.1lbs) |
|---|
| Mounting Options | Ceiling & wall |
|---|
